Connector Options
Ultraplate
WBT-0102 Cu
WBT-0102 Ag
XLR
Basic Electrical Specifications
AGDL XLR
DUT: AGDL 1m terminated with XLR type connectors.
| (Cp) parallel capacitance: | 37.10 pF @ 20 kHz |
| (Ls) series inductance: | 1.05 µH @ 20 kHz |
| (Rdc) dc loop resistance: | 0.119 Ω |
| (Xt) total reactance: | 0.132 Ω @ 20 kHz |
| Frequency response ± 0.5 dB dc - 10 MHz | |
AGDL
Construction featuring our proven tri-braid field geometry and VariStrand™, Hyper-pure silver conductors. AGDL is configured for balanced digital data transmission. Designed specifically for digital applications in lengths from 0.5 through 10.0 meters, AGDL offers accurate, detailed and dynamic performance. The design philosophy is not transmission line based nor does it use metallic or semi-conductive screens. AGDL is available factory terminated with "studio grade" XLR type connectors with silver plated contacts. Also available with the Kimber Ultraplate RCA type connector.
